Input (DC)

Max. DC power (@ cos φ=1)

12250 W

Max. input voltage

1000 V

MPP voltage range / rated input voltage

380 V – 800 V / 600 V

Min. input voltage / initial input voltage

150 V / 188 V

Max. input current input A / input B

22 A / 11 A

Max. input current per string input A** / input B**

33 A / 12.5 A

Number of independent MPP inputs / strings per MPP input

2 / A:4; B:1

Output (AC)

Rated power (@ 230 V, 50 Hz)

12000 W

Max. apparent AC power

12000 VA

Nominal AC voltage

3 / N / PE; 220 / 380 V 3 / N / PE; 230 / 400 V 3 / N / PE; 240 / 415 V

Nominal AC voltage range

160 V – 280 V

AC power frequency / range

50 Hz, 60Hz / -6 Hz ... +5 Hz

Rated grid frequency / rated grid voltage

50 Hz / 230 V

Max. output current

19.2 A

Power factor at rated power

1

Adjustable displacement factor

0.8 overexited ... 0.8 underexited

Phase conductors / connection phases

0.3 Mrz

Efficiency

Max. efficiency / European efficiency

98.1 % / 97.7 %

Protective devices

Input-side disconnection device

yes

Ground-fault monitoring / grid monitoring

yes / yes

DC surge arrester Type II, can be integrated

opt.

DC reverse-polarity protection / AC short-circuit current capability / galvanically isolated

yes / yes / —

All-pole sensitive residual current monitoring unit

yes

Protection class (according to IEC 62103) / overvoltage category (according to IEC 60664-1)

I / III

General data

Dimensions (W / H / D)

665 / 690 / 265 mm

Weight

64 kg / 141.1 lb

Operating temperature range

-25 °C ... +60 °C /

Noise emission (typical)

51 dB(A)

Self-consumption at night

1 W

Topology / cooling concept

Transformerless / OptiCool

Degree of protection (according to IEC 60529)

IP65

Climatic category (according to IEC 60721-3-4)

4K4H

Maximum permissible value for relative humidity (non-condensing)

1

Features

DC terminal

SUNCLIX

AC terminal

Spring-type terminal

Display

Graphic

Interface: RS485 / Bluetooth/ Webconnect / Speedwire

opt. / yes/ opt. / opt.

Warranty: 5 / 10 / 15 / 20 / 25 years

yes / opt. / opt. / opt. / opt.

Multi-function relay / Power Control Module

opt. / opt.
